Roofing and roofing membrane WÜTOP® TRIO UV 2SK

In combination with a WÜTOP vapour barrier/barrier and the EURASOL adhesive tapes, modern airtight and windproof constructions can be designed in accordance with the current EnEV.

Suitable as a temporary covering/outdoor weathering period

4 weeks without seam and perforation protection, 8 weeks with seam and perforation protection

Technology

3-layer polypropylene-based underlay with special functional membrane.

Safety

Reduced risk of slipping due to PP cover fleece and additional protection of the inner membrane due to 3-layer construction.

Time and cost savings

Simple and fast installation thanks to integrated adhesive strips (2SK).

Specially designed for slate

According to the ZVDH, it is particularly suitable as a pre-covering for slate

Note

Please note the applicable ZVDH guidelines and the installation instructions for this product.

Meets the requirements of ZVDH product data sheet of class UDB-A/USB-A.

10-year system warranty

Application Use

as a roofing membrane (UDB-A) and underlay (USB-A)

Use of the WÜTOP Trio UV 2SK as an airtightness membrane possible

Long outdoor weathering and high temperature resistance in the standard class.

• Surface weight per m²: 150 g
• Roll length: 50 m
• Roll width: 1.5 m
• Area: 75 m²
• Number of rolls per pallet: 28 PCS
• Material: PP - Polypropylene
• Temperature resistance min./max.: -40 to 100 °C
• Building material class / Condition: E - Normally flammable / according to DIN EN 13501-1
• Water vapour diffusion equivalent air layer thickness / Condition: 0.06 m / according to EN 1931
• Resistance to water passage: W1
• Resistance to tearing (longitudinal): 190 N
• Resistance to tearing (transverse): 200 N Tensile
• force longitudinal at 50 mm: 310 N
• Tensile force transverse at 50 mm: 300 N
• Suitable as a pre-covering for slate: 8 weeks
• Suitable as a temporary covering/outdoor weathering period: 8 weeks
• UV resistance: Max. 6 months
• Building material class: E - Normally flammable
