The core of the Steko wall system is a wooden module that can be put together in layers to form entire walls in the simplest way. The individual modules are coupled to each other by a special plug-in bond, so that an optimal connection of the corners and the partition wall connections is also guaranteed. Coordinated end, lintel and beam elements for the different opening types simplify wall construction. Tube-like cables can be routed in the hollow chambers of the Steko module. The subsequent insulation of these hollow chambers ensures efficient thermal insulation. The additional external insulation further improves thermal insulation and predestines the system for the construction of Minergie, low-energy and passive energy houses.
The Steko timber construction system is based on a few basic elements, which can be put together quickly and easily. The core piece is the handy basic module weighing approx. 6.5 kg with a length of 640 mm and a height of 320 or 240 mm. The width of all components is 160 mm. In addition to the 4-part module, there are 3-, 2- and 1-part modules.
A threshold is used as the lower end, and a tie-in with a height of 8 cm each as the upper end. With the soffit boards, the system is complete. With these few parts, all load-bearing or non-load-bearing interior and exterior walls of a house can be built.
The horizontal grid is set at 16 cm and the vertical grid at 8 cm. Intermediate steps are also possible. This enables efficient planning with almost unlimited design freedom.
