AluK 72BW HI

Aluk (UK) Ltd

Beschreibung

This three chamber aluminium window system has been designed to offer the highest levels of performance, alongside the flexibility to tailor configurations to your requirements.

Mehr Über

The 72BW HI aluminium window system incorporates our patented Spidertechnology® ABS strips that allow you to achieve high thermal insulation. The system has been certified under the Secured by Design scheme and incorporates high security multipoint-locking systems and a range of window and door furniture. The 72BW HI window system provides complete flexibility and the ultimate performance to meet the needs of the most demanding project. Available in a wide range of configurations, finishes and colours, the system can be adapted and configured to complement the design of your building.

Design Features

  • Three chamber high performance window system for exceptional stability
  • Both aluminium and PVC groove hardware available
  • Wide range of styles and configurations to choose from
  • A variety of finishes and detailing are available to suit your project
  • Customisable components to reach desired thermal performance specification
  • All certified under Secured by Design scheme

Technische Informationen

U-Value (Double Glazing): 1.4 W/m²K

U-Value (Triple Glazing): 1.0 W/m²K

Green Guide Rating. B Rated

Acoustic Performance (dB): Rw (C;Ctr) 44 (-2;-6) dB

Air Tightness (Pa): Class 3 (600 Pa)

Water Tightness (Pa): Class 7a (300 Pa)

Wind Load (Pa): Class 4 (1600 Pa)

Security: PAS24

Secured By Design: Yes
