The AS|70 PVC-U window with stop seal is based on 5-chamber technology. This window has excellent thermal insulation properties with narrow face widths at the same time.
More Over
Fittings
Basic Security
Security tilt strike plate bottom
Security strike plate top
Solid frame Sash
profiles with steel reinforcement
RC 1 Security (WK 1)
Tested security according to DIN EN 1627 ff
Adjustable mushroom head locks with burglar-resistant security strike plates on all four corner areas Window
handle lockable (100 Nm)
Solid frame and sash profiles with steel reinforcement
RC 2 security (WK 2)
Tested security according to DIN EN 1627 ff, recommended by the criminal investigation department
Circumferential adjustable mushroom head locks with burglar-resistant security strike plates Lockable
window handle (100 Nm)
Additional steel drilling protection Safety
glazing A3 (P4A)
Secured glass pane by gluing
Solid frame and sash profiles with reinforced steel reinforcement
Technical Information
General
5-chamber system
70 mm installation depth
2-fold sealing system
Safety
Safety up to resistance class RC 2 (WK 2)
Basic safety standard
Thermal insulation
Thermal insulation up to Uw=0.91 W/m²K*
Thermal insulation Uw=1.3 W/m²K*
Thermal insulation Uw=1.4 W/m²K* without warm edge
Sound insulation
Sound insulation up to SSK 5 (up to Rw,P=48 dB)*
Features
Rainwater-protected area for the fittings in the rebate area
