HELLA ARB 80 external venetian blind

With the ARB 80 model, HELLA offers a high-quality external venetian blind with edge-flanged, 0.45 mm thick and 80 mm wide C-slats that offer ideal sun, privacy and heat protection. The model has a low-noise wind protection and the intelligent HELLA Omega punching as a slat connection. Flanged hole punches protect the elevator belts and eliminate the need for plastic clips. ARB 80 can be guided by rope or rail and driven by a crank or motor. On request, the ARB 80 external venetian blind is also available with daylight control.

• Slat width [mm]: 80
• Slat type: edge flanged
• Side guide: rope/guide rail
• min. width [mm]: 400 (crank)/430 (motor)
• max. width [mm] Single system: 5000 (crank/motor)
• max. hanging area [m²] Single system: 14 (crank)/20 (motor)
• max. hanging area [m²] coupled systems: 12.6 (crank)/22.5 (motor)
• max. height [mm]: 5200 (crank/motor)
