HAHN S9-iVt-05

HAHN Lamellenfenster GmbH

Description

The HAHN louvre window S9-iVt-05 impresses with its excellent properties in terms of ventilation, tightness and thermal insulation as well as burglary protection (RC2). The characteristic appearance is characterised by the glass slats set in aluminium profiles.

The S9-iVt-05 is certified as a natural smoke and heat exhaust ventilation device (EN 12101-2). Tested ball impact safety for sports facilities (DIN 18032-3).

More Over

Profiles

element frame: AL profiles, thermally separated
Slat frame: AL profiles, thermally separated

Dimensions

element width: min. 250 mm, max. 2000mm
Element height: min. 200 mm, height is not limited
Slat height: min. 150 mm, max. 400 mm [>350 mm statically to be checked in individual cases]
Frame depth: 47 mm
Max. opening angle: 84°

glazing

Glazing: Insulating glazing (2/3-fold)
Glass thickness: 28 / 32 mm
Standard glass structure: 6 / 16 / 6
Glass types: Float, ESG, LAMINATED SAFETY GLASS, TVG
Alternative fillings: Composite panels

Operation

Manual, electric, pneumatic

Surfaces

anodised, powder-coated

Technical Information

Performance characteristics

CE-certified NSHEV (EN 12101-2): SHEV
Aerodynamic coefficient Cv: 0.56
Air permeability (EN 12207): Class 3
Driving rain tightness (EN 12208): Class 4A
Resistance to wind stress:
Tested Uw value (EN ISO 10077): Uw (max) = 1.6 W/m2K
Other features: Burglar-resistant RC2, ball-proof (DIN 18032-3), sound insulation tested (EN 14351-1), fall protection according to TRAV 2003
