INDULCLIP Ceiling Air Diffuser

Kiefer Klimatechnik GmbH

Description

NDULCLIP, INDUDRALL and KOMBICLIP are distinctive air diffusers. Available in different shapes and colours, they are often used as aesthetic design elements for ceiling architecture. These ceiling air diffusers enable very good air distribution and thus also meet high requirements for room comfort.

More Over

The strengths of INDULCLIP:

Energy:

Low pressure losses and high temperature differences are the prerequisites for energy-efficient operation in the air conditioning system as a whole.

Architecture:

A large number of different design variants, shapes and colours allow plenty of freedom for individual ideas and design wishes. A ceiling air diffuser does not always have to be round or square!

Technology:

The flow-optimised Kiefer air duct elements enable draught-free air supply even under demanding conditions.

Technical Information

Sizes: 300 mm - 800 mm
Designs: round and square
Supply air temperature difference: up to -12 K
Volume flow: 100 - 1500 m³/h
Room heights: 2.3 m - approx. 8 m
Front panel: RAL of your choice
Individual elements: black or light grey (RAL 7035), other colours possible on request
Throttle valve: adjustable from the room
