Typical of the corrugated profile 18/76 is its slightly pronounced wave structure. The waves appear even and restrained. They create soft light-shadow effects. The façade, wall and roof are given a fine, harmonious appearance.
More about
- Classic, slightly pronounced wave structure
- One of the most popular corrugated profiles
- For cladding roofs, walls and façades
- Installation direction: vertical, horizontal, diagonal
- Mounting type: visible
Aluminium version:
- Material data: DIN EN AW 3105 H48 according to DIN EN 485-2
- Material thicknesses: 0.50/0.60/0.70/0.80/0.90/1.00 mm
- Weight: approx. 1.60 - 3.20 kg/m²
- Delivery length: up to 12.00 m, other lengths on request
Steel Design:
- Material data: DIN EN 10346:2009-07
- Material thicknesses: 0.50/0.63/0.75/0.88/1.00 mm
- Weight: approx. 4.70 - 9.10 kg/m²
- Delivery length: up to 12.00 m, other lengths on request
