More Over
The carrier boards are made of calcium sulphate or wood-based panels. The galvanised, infinitely adjustable metal feet offer maximum installation freedom.
Characteristics of this flooring system are:
Technical Information
Construction principle - Floor slab :
The Mero Combi T hollow floor can be made of single or two-layer gypsum fibre boards, wood-based panels or cement-bonded panels. All plates are provided with a tooth milling all around. The panel joints are glued together. Factory application of certain types of stone, porcelain stoneware or parquet is possible.
Construction principle - substructure :
The MERO substructure consists of infinitely height-adjustable steel columns. The dimensioning and the column spacing are variable according to load requirements and overall height.
Base course
Dimensions: 600x600 or 596x596 mm (Aqua)
System weight: 23 kg/m2 to 125 kg/m2
Board material: gypsum fibreboard, wood-based panel, cement-bonded board
Adhesive: tooth milling glued together; high-quality solvent-free adhesive
Substructure
Grid dimension: 600 x 600 mm
Supports Material: Steel, galvanised
Mounting height: from 50 mm
Column fastening: usually glued to the subfloor and to the slab; infinitely variable height adjustment
Coverings
Textile and elastic floor coverings, parquet, natural stone, artificial stone, liquid coatings
Load values
Point load: 2,000 – 20,000 N
assessed according to DIN EN 13213: Class 1 – 6
Breaking load: > 4,000 – 40,000 N
Fire protection
Building material class Carrier board according to EN 13501 T1: A1 possible
Fire resistance class according to DIN 4102 T2: F30 possible
Sound insulation values
