INTELLO PLUS

Pro Clima

Description

Reinforced hydrosafe® high-performance vapour barrier for all fibrous insulation materials

Use in roofs, walls, ceilings and floors in externally permeable and diffusion-tight constructions, e.g. flat/pitched roofs and green roofs according to design.

More Over

Best protection against structural damage and mould because it is damp with a spread of more than 100 times
Test winner at Stiftung Warentest 4/2012
Permanently safe: Function officially tested and confirmed (ETA-18/1146)
Safe winter construction sites thanks to Hydrosafe® function
Can be combined with all fibrous insulation materials (including blow-in insulation)
Easy to process: Dimensionally stable, no splicing or tearing
Best values in the pollutant test, test carried out according to AgBB / ISO 16000

Technical Information

Colour: white-transparent

· Surface weight: DIN EN 1849-2 110 g/m²

Thickness: DIN EN 1849-2 0.4mm
Vapour diffusion resistance coefficient μ: DIN EN 1931 35,000
Sd value: EN 1931 14m
sd value humid quality: DIN EN ISO 12572 0.25 - >25 m
Reaction to fire: EN 13501-1 E
Fire code (CH): VKF 5.3
Airtightness: DIN EN 12114 carried out
Maximum tensile force longitudinal/transverse: DIN EN 13859-1 (A) 340 N/5 cm / 220 N/5 cm
Elongation/transverse: DIN EN 13859-1 (A) 15 % / 15 %
Tear propagation resistance longitudinal/transverse: DIN EN 13859-1 (B) 200 N / 200 N
Durability according to artificial specifications. AgeingETA-18/1146 passed
Temperature resistance: permanent -40 °C to +80 °C
Thermal conductivity: 2.3 W/(m·K)
Material guarantee, deposited: ZVDH yes
CE marking ETA-18/1146 available
