PENTAFLEX KB

H-BAU Technik - a brand of PohlCon GmbH

Description

PENTAFLEX® is a joint sealing system for the construction of water-impermeable concrete structures (white tank). The PENTAFLEX KB® joint sheet elements are ideally suited for use in precast and in-situ concrete construction and were designed for buildings with high-quality use. They are provided with a special coating on both sides, which, in combination with the fresh concrete, reliably prevents water from infiltrating the joint system. PENTAFLEX KB® elements can be used for all construction joints and installation variants (horizontal/vertical, pressing/non-pressing water).

More Over

PENTAFLEX KB® 167

Coated joint sheet for sealing horizontal and vertical construction joints against pressurized and non-pressurized water, as well as against soil moisture, and install in compliance with the manufacturer's instructions in accordance with ETA 15/0003 and general building inspection test certificate P-5120/231/09 MPA-BS.

PENTAFLEX KB® 80

Coated joint sheet for sealing horizontal and vertical construction joints against pressurized and non-pressurized water, as well as against soil moisture, and install in compliance with the manufacturer's specifications in accordance with ETA 15/0003 and the general building inspection test certificate P-5120/231/09 MPA-BS.

PENTAFLEX KB® Corner

Coated, factory-manufactured fitting for corner formation in the floor slab in the case of element wall construction for the connection of the vertical working joints against pressing and non-pressing water, as well as against soil moisture, and install in compliance with the manufacturer's specifications in accordance with ETA 15/0003 and the general technical test certificate P-5120/231/09 MPA-BS.

Technical Information

PENTAFLEX KB® 167

Sheet width: 167mm
Minimum embedding depth: 30mm
Standard line for visual installation inspection
Permissible water pressure: 2.0bar
Delivery including all necessary fasteners (retaining brackets, bumpers).

PENTAFLEX KB® 80

Sheet width: 80mm
Minimum embedding depth: 30mm
Permissible water pressure: 1.0bar
Delivery including all necessary fasteners (retaining brackets, bumpers).

PENTAFLEX KB®

Corner Sheet width: 167mm
Minimum embedding depth: 30mm
Standard line for visual installation inspection
Permissible water pressure: 2.0bar
Delivery including all necessary fasteners (butt clamps).
