The electraplan sewer system flush with the screed. BK can be used for flat screed heights from 30 mm. The standard duct width of up to 600 mm is extremely generous, and the manhole covers can also be opened after installation. Tehalit. BKB is a "parapet duct in the ground" and is installed along walls or window fronts. The devices can be installed at any point. The upper part of the duct is available in three variants: closed, with brush outlet or with brush outlet and LED.
More Over
Floor duct flush with the screed for dry-maintained floors in accordance with DIN VDE 0634 Part 1
Equipment installation with equipment carriers
Easy access thanks to removable upper part and wall-side cable outlet (outlet brush)
Minimum height screed 96 mm
upper part can be covered with all types of floor coverings (parquet, carpet, stone or laminate) (0 - 25 mm)
Height levelling of the duct via internally accessible adjustment screws
Loadable up to 1500 N according to DIN EN 50085-2-2 Class 6.102.4
Minimum recommendation: 4 levelling screws and 4 fastening screws per running metre (not included)
Retrofitting for energy and data without great effort
important: Installation of edge insulation strips between sewer and screed
Observe earthing measures
Delivery colour: black
Delivery form: Duct consisting of lower part with mounting cover, upper part separately
